Mitsubishi AA084VC04 In-Stock

#AA084VC04 Mitsubishi AA084VC04 New Mitsubishi 8.4 inch LCM 640×480 480 500:1 65/65/50/60 262K CCFL TTL, AA084VC04 pictures, AA084VC04 price, #AA084VC04 supplier
——————————————————————-
Email: sales@shunlongwei.com

https://www.slw-ele.com/aa084vc04.html

——————————————————————-

Brand Mitsubishi
Model AA084VC04

Diagonal Size 8.4 inch
Type a-Si TFT-LCD, LCM

Pixel Format 640(RGB)×480 [VGA] 95PPI
Configuration RGB Vertical Stripe

Active Area 170.88(H)×128.16(V) mm
Outline Dim 199.5(H)×149(V) ×12(D) mm

Bezel Area 174.9(H)×132.2(V) mm
Treatment Hard coating (2H), Antireflection

Luminance 480 cd/m² (Typ.)
Contrast Ratio 500:1 (Typ.) (TM)

View Direction 6 o'clock
Response Time 6/19 (Typ.)(Tr/Td)

Viewing Angle 65/65/50/60 (Typ.)(CR≥10) Left / Right / Up / Down
Operating Mode TN, Normally White, Transmissive

Support Color 262K 39% NTSC
Light Source CCFL [2 pcs] , 50K hours , W/O Driver

Weight360g (Typ.) Designed For Industrial

Frame Rate60Hz

120Hz (60HZ Input) : Embedded MEMC circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC circuit
Touch Panel Without

Interface Type CMOS (1 ch, 6-bit) , 31 pins Connector

Power Supply 3.3V (Typ.)(VCC)

Environment Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -20 ~ 80 °C

AA084VC04 inverter, AA084VC04 power supply, AA084VC04 electronic board, AA084VC04 VGA board, AA084VC04 touchscreen available.

Shunlongwei Inspected Every AA084VC04 Before Ship, All AA084VC04 with 6 months warranty.
